Dupont Cable with Safety Clip
Dupont cable with JST-XH6 connector
$1.92
⚡Free shipping on orders over $70.⚡
Related:
Features & Advantages
- Cable with fuse
- 700mm length
- For Nema17 motors
Description
700 mm, Dupont cable, 4-pin connector with locking function on 6-pin JST-XH6 connector.
By default, this cable is intended for the 40mm Nema17 geared motor. Make sure that it conforms to the circuit diagrams for your application.
You can find the specified cabling for this cable here:
Controller side / motor side
| Control side | Motor side |
| PIN 1 | PIN 1 |
| PIN 2 | PIN 4 |
| PIN 3 | PIN 3 |
| PIN 4 | PIN 6 |
If it is to be used with our 25mm pancake motor, swap the position of the two center wires to get a correct connection as below.
| Control side | Motor side |
| PIN 1 | PIN 1 |
| PIN 2 | PIN 3 |
| PIN 3 | PIN 4 |
| PIN 4 | PIN 6 |
